FastTrans - Insulation stressed with fast rise time repetitive voltages from high voltage power electronics

FastTrans - Insulation stressed with fast rise time repetitive voltages from high voltage power electronics

High voltage power electronic converters are central elements in the physical infrastructure of any flexible energy system because they enable effective switching and seamless control of the power flow between the different suppliers and consumers in the electric power grid. However, the rapid switching of power electronic converters cause voltage surges with fast rise times that can inflict more severe stress on the insulation of electrical apparatus than traditional stress caused by pure sinusoidal voltages.

Today, the industry's factory acceptance stress tests for high voltage electrical equipment used in converter-fed networks are still largely based on conventional, slow 50 Hz sinusoidal voltages because there is a lack of reliable international test standards for insulation coordination under power electronic stresses.

FastTrans aims to address these issues by developing knowledge, equipment, models and techniques for testing and insulation coordination of high voltage electric power apparatus in networks stressed with fast rise time repetitive voltage pulses from power electronics.

The project focuses on three specific R&D challenges that are particularly important for the development of generic test standards:

  1. Partial discharge occurrence and detection
  2. Pulse propagation in networks into components
  3. Ageing diagnostics

The project accommodates the full diversity of high voltage insulation systems, which range from the µm-sized and sharp-edged internal insulation in an integrated gate bipolar transistor (IGBT), to more uniform geometries in polymer cables, epoxy-insulated machines, and oil/cellulose-insulated transformers.

The research documentation emanating from the project is expected to be sufficiently comprehensive to approach international organisations such as IEC and CIGRE for the development of generic and reliable test standards for high voltage equipment under the influence of fast transient stresses from power electronics.

Project partners:

  • Infineon
  • Statnett SF
  • Equinor Energy AS
  • ABB AS
  • Statkraft Energi AS
  • Hafslund Nett AS
  • Aker BP AS
  • Total E&P NORGE AS




This is a KPN-project (Knowledge-building Project for Industry) financed by the Research Council of Norway.




Published 15 October 2019
Chief Scientist

Project duration

2019 - 2023
