SINTEF Offshore Blowout Database

SINTEF offshore blowout database is a comprehensive event database for blowout risk assessment. The database, per November 2021, includes information on 702 offshore blowouts/well releases that have occurred world-wide since 1955 and overall exposure data from the US Gulf of Mexico, Outer Continental Shelf and the North Sea. The blowouts/well releases are categorized in several parameters, emphasizing blowout causes. A user-friendly interface allows for customized search patterns.

Contact person

Photo: Shutterstock

Participants

The SINTEF Offshore Blowout Database was initiated in the mid 80’s. ExproSoft (now a part of Peloton) has been contracted to operate the Offshore Blowout Database from 1 May 2001 by SINTEF.

The Participants of the Project are (November 2021):

  1. Aker BP ASA
  2. Akvaplan-niva as
  3. BP America Production Company
  4. ConocoPhillips Skandinavia AS
  5. DNV AS
  6. Equinor ASA
  7. Lundin Energy Norway AS
  8. Marex Marine & Risk Consultancy
  9. Ranold AS
  10. Safetec Nordic A/S
  11. Shell Global Solutions International
  12. Vår Energi AS
  13. Vysus Group (former Lloyds)

Blowout descriptions in the database

The database contains 51 different fields describing each blowout/well release. In addition, the database allows for attachment of any electronic file(s) to the blowout description. The various fields are grouped in six different groups:

  1.  Category and location
  2. Well description
  3. Present operation
  4. Blowout causes
  5. Blowout characteristic
  6. Other


Category and location
Includes information related to the incident category (blowout vs. well leak), offshore installation such as location, operator, installation name and type, and water depth.

Well description
Includes well and casing depths, last casing size, mudweight, bottom hole- and shut in pressure, GOR, formation age and rock type.

Present operation
Includes the operational phase (exploration drilling, development drilling, workover etc.), the operation presently carried out (for example casing running) and the present activity (for example cementing).

Blowout causes
Includes external cause (stating if an external cause contributed to the incident), loss of the primary barrier, loss of the secondary barrier (describing how primary and secondary barriers were lost) and human error. It should be noted that the field regarding human error in general holds low quality information. Human errors are frequently masked. A field named North Sea standards highlights if the development of the blowout could have been avoided if North Sea type equipment had been used (for instance in other parts of the world a blind shear ram is not mandatory in surface BOP stacks).

Blowout characteristics
Twelve fields are included comprising flow path, flow medium, flow rate (low quality), release point, ignition type, time to ignition, lost production (low quality), duration, fatalities, consequence class, material loss and pollution.

Other
In the “other” screen five fields are included: control method, remarks (includes a description of the incident, data quality (includes an evaluation of the source data quality), last revision date and references.

Exposure data

The overall offshore drilling and production exposure data for the US GoM OCS, Norwegian, and UK waters is covered from 1 January 1980. In addition, drilling exposure data for the Dutch Continental Shelf, the east Coast of Canada, Australian waters, Danish waters, Brazilian waters, and the US OCS Pacific are included.

Search possibilities and reporting facilities

Almost any type of search may be performed to select specific blowout /well release event types. Search criteria may be established by selecting predefined codes, specific numeric values, specific free text, or any combinations of these. The predefined codes are spelled out to ease understanding.

The database program counts and presents the events satisfying the search criteria. The selected data may be viewed, printed or copied to separate files for further analyses, for example by database or spreadsheet programs.

The exposure data and the blowout data are not linked. Blowout frequencies can therefore not be established directly.

Some definitions

The following main definitions have been applied when classifying the blowouts/well releases in categories and sub-categories.

Blowout: A blowout is an incident where formation fluid flows out of the well or between formation layers after all the predefined technical well barriers or the activation of the same have failed.

Well release: The reported incident is a well release if oil or gas flowed from the well from some point were flow was not intended and the flow was stopped by use of the barrier system that was available on the well at the time the incident started.

Shallow gas: Any gas zone penetrated before the BOP has been installed. Any zone penetrated after the BOP is installed is not shallow gas (typical Norwegian definition of shallow gas).

Category and Sub-category

The categories and subcategories applied when classifying the incidents in the SINTEF Offshore Blowout Database are shown in Table 1.

Table 1. Main categories and subcategories for the incidents in the SINTEF Offshore Blowout Database

Main Category Sub category Comments/Example
Blowout and well release Surface blowout Totally uncontrolled flow, from a deep zone Totally uncontrolled incidents with surface/subsea flow.
Totally uncontrolled flow, from a shallow zone Typical the diverter system fails
Shallow gas "controlled" subsea release only Typical incident is that riserless drilling is performed when the well starts to flow. The rig is pulled away
Under-ground blowout Underground flow only
Underground flow mainly, limited surface flow The limited surface flow will be incidents were a minor flow has appeared, but typical the BOP has been activated to shut the surface flow
Well release Limited surface flow before the secondary barrier was activated Typical incident will be that flow is through the drillpipe and the shear ram is activated
Tubing blown out of well, then the secondary barrier is activated Typical incident occurring during completion or workover. Shear ram is used to close the well after the tubing has been blown out of the well.
Diverted well release Shallow gas controlled flow (diverted) All incidents were the diverter system functioned as intended.
Unknown Unknown Unknown may be selected for both the category and the subcategory



Scope of data

Totally the database includes 702 offshore blowouts worldwide (November 2021). Data from the US Gulf of Mexico Outer Continental Shelf (US GoM OCS), Norwegian and UK waters are in general better documented than blowouts from other regions.

From 1 January 1980 through 31 December 2019, a total of 313 blowouts/well releases from the US GoM OCS and the North Sea were consolidated in the database. Table 2 shows an overview of blowouts occurrence by operational phase.

Table 2. Number of blowouts experienced during different operational phases.

AREA Dev. drlg Unk. drlg Comp-letion Work-over Production Wire-line Abandoned well Unknown/other Total
External cause* No ext. cause* Ext. cause* No ext. cause*
US GoM OCS 58 1 14 46 11 17 6   3 1 217
26,7% 0,5% 6,5% 21,2% 5,1% 7,8% 2,8%   1,4% 0,5% 100,0%
Norwegian & UK waters 12 2 7 17 1 8 10   2   94
12,8% 2,1% 7,4% 18,1% 1,1% 8,5% 10,6%   2,1%   100,0%
Total 70 3 21 63 12 25 16 0 5 1 311
22,5% 1,0% 6,8% 20,3% 3,9% 8,0% 5,1% 0,0% 1,6% 0,3% 100,0%

* External causes are typical, storm, military activity, ship collision, fire and earthquake.

Access to the database and reports

The database and annual report are confidential and only accessible for the project sponsors. The SINTEF Offshore Blowout Database is open to new participants. Some statistics from the database are presented in the following references:

Holand, Per:
“Loss of Well Control Occurrence and Size Estimators”, Exprosoft report ES201471, Trondheim, Norway, May 2017

Holand, Per:
"Offshore Blowouts Causes and Trends" Doctoral Dissertation, Norwegian Institute of Technology, Department of Production and Quality Engineering, Trondheim, Norway, March 1996

Holand, Per:
"Experienced Offshore Blowout Risk" presented at the IADC 1996 Well Control Conference of the Americas, Rio de Janeiro 31. July - 2. August 1996.

Holand, Per:
"Offshore Blowouts Causes and Control", Gulf Publishing Company, Houston Texas, 1997

For further information please contact:
or

Key Factors

Project start

1990
