Sand Production Prediction

SandPredictor is a user-friendly analytical volumetric sand production tool for field prediction.

Contact person

The user can check the influence of planned oil production strategies on the amount of expected sand, and thus tailor both draw-down and depletion scenarios so as to minimise sand production during the whole expected life of the reservoir.

SandPredictor uses a semi-empirical sand production model developed in the Sand Production JIP. The model is a combination of analytical borehole stress calculation together with correlations developed from extensive hollow-cylinder sand production laboratory tests; these correlation factors predict the stress for onset of sand and the mass of produced sand as a function of stress state and fluid flow rate.

The SandPredictor System consists of the following elements:

  • User-friendly interface
  • Calculates sand production based on intended draw-down and assumed depletion field history
  • Allows reservoir properties’ input parameters from log
  • Suggests default sand onset stress from SINTEF correlations, or user defined ones
  • Calculation for either open-hole or perforated well
  • Any well inclination allowed
  • Wealth of possible data in plotting options
