Agilent 990 Micro GC

• Two channels
• Dual carrier gas option
• Max 180 °C column temperature
• Thermal conductivity detector (TCD)
• Molsieve 5A 10 m column
• PoraPLOT U 10 m column
• LOD typically low ppm mol level
• Genie filter
• Soprane 2 Software
• Transportable, weight 7.3 kg

The instrument is a self-contained gas chromatograph unit with its own micro-machined injector, columns, and thermal conductivity detector (TCD), all built into a single cabinet, so it can operate as a standalone GC instrument for gas analysis. The instrument has two channels, where Molsieve 5A (MS5A) and PoraPLOT U (PPU) columns are installed. This configuration makes the 990 Micro GC ideal for analysis of N2, O₂, CO₂, CO, H₂, CH₄ and hydrocarbons C1-C6. The Genie membrane filter uses a semipermeable membrane to remove droplets and particles from the sample gas stream, ensuring proper injector function for long-term, reliable results.

Field of use

Typical applications include environmental emissions monitoring, process gas monitoring, hydrogen fuel quality control, and other applications requiring real-time gas measurement.
