Special equipment provided by the project

    • Equipment for partial discharge testing of insulations in power electronics environment

            • Conventional, optical and acoustic measurement
            • High Voltage Amplifier
              • Sinusoidal high voltage source
              • Slow rise square wave high voltage source
            • High speed camera for optical PD visualization
            • Photomultiplier for optical PD detection
            • Acoustic sensor for acoustic detection



    • Test setup including small pressure vessel for electric and optic PD measurement








      • Equipment for contamination control (Filters for liquids, flow bench)
      • Keyence microscope for inspection of cleanliness







      • Test cell (climate chamber) for long-term dielectric voltage stress in various insulation liquid environments





      •  Infra-red (IR) - to monitor structural changes between the materials
      • Ultra Violet (UV) – To monitor colour changes

      • Isothermal microcalorimetry (IMC) is a laboratory method for real-time monitoring and dynamic analysis of chemical, physical and biological processes

      • Differential Scanning Calorimetry (DSC)









    • Test setup for investigating possible erosion of thin capacitor PP-film metallization





    • Test cell for live experiments with capacitors in pressurized environment



    • Test circuit and cell for experiments with live converter modules in high pressure environment
